Flexeble PvC Insulated PVC Sheathed Circular Sheathed Copper Cable

The full name of RVV wire is copper core PVC insulated PVC sheathed flexible wire, also known as lightweight PVC sheathed flexible wire, commonly known as soft sheathed wire, which is a type of sheathed wire. Mainly used for power lines, control lines, and signal transmission lines for electrical appliances, instruments, electronic equipment, and automation devices. Specifically, it can be used for anti-theft alarm systems and building intercom systems

Product Performance

Product Name: RVV Cable, RVV Wire and Cable

Rated voltage: 300V/500V.

Conductor: multi stranded copper conductor, in accordance with GB/T 3956 Class 5 (equivalent to IEC60228.5).

Insulation: Polyvinyl chloride mixture (PVC).

Sheath: Flexible polyvinyl chloride mixture (PVC), gray (RAL7001).

Core wire identification: ≤ 5 cores, colored core wire; Black core wire with white numerical code, yellow green ground wire.

Core number: 2-5 cores, 7-36 cores (products outside the CCC catalog, without CCC certification).

Cross sectional area: 0.75-2.5mm ², 0.5, 2.5-35mm ² (products outside the CCC catalog, without CCC certification).

Test voltage: 2000V, 5 minutes.

Insulation resistance:>200M ohms x KM.

Operating temperature: -30~+70 ℃.

Bending radius: 15 times the outer diameter of the cable.

Flame retardant properties: IEC 60 332.1.

Reference standards: GB 5023, IEC60227, HD VDE21.5 S3.

Packaging specifications: 100m, 500m, 1000m.

Application

RVV cable is mainly used in flexible usage areas such as medium and light mobile appliances, instruments, household appliances, power lighting, etc. It can transmit control signals and power signals, and is also suitable for laying in cable trays and hoses













Parameter Table

Cross Sectional Area	Cable diameter	Insulation thickness	Jacket	max.cond.	Rated Voltage	Weight per 100 meters	Length(m) per Roll
(mm2)	(O.D. mm)	(mm)	thickness	resistance	(V)
			(mm)	(Ω/KM,20°C)
2X0.2	3.7土0.2	0.5	0.7	92.3	300/300V	1.94KG	100/roll 200/roll
2X0.3	4.2土0.2	0.5	0.7	69.2	300/300V	2.52KG
2X0.5	5.2土0.2	0.6	0.7	39	300/300V	3.81KG
2X0.75	5.8土0.2	0.6	0.8	26	300/500V	4.96KG
2X1.0	6.6土0.2	0.6	0.8	19.5	300/500V	6.33KG
2X1.5	7.4土0.2	0.7	0.8	13.3	300/500V	8.9KG
2X2.5	8.8土0.2	0.8	1	7.98	300/500V	12.69KG
2X4.0	9.6土0.2	0.8	1.2	4.95	300/500V	16.45KG
2X6.0	12.2土0.2	0.9	1.2	3.65	300/500V	25.85KG
3X0.2	3.8土0.2	0.5	0.7	92.3	300/300V	2.2KG
3X0.3	4.3土0.2	0.5	0.7	69.2	300/300V	2.84KG
3X0.5	5.4土0.2	0.6	0.7	39	300/300V	4.48KG
3X0.75	6.0土0.2	0.6	0.8	26	300/500V	5.73KG
3X1.0	6.8土0.2	0.6	0.8	19.5	300/500V	7.66KG
3X1.5	7.8土0.2	0.7	0.8	13.3	300/500V	10.94KG
3X2.5	9.3土0.2	0.8	1	7.98	300/500V	15.6KG
3X4.0	10.4土0.2	0.8	1.2	4.95	300/500V	21.14KG
3X6.0.	13.2土0.2	0.9	1.2	3.65	300/500V	33KG
3X10.0	17.2土0.2	1.1	2	4.95	300/500V	54.43KG
3X16.0	19.3土0.2	1.1	2	3.65	300/500V	74KG
4X0.2	4.2土0.2	0.5	0.7	92.3	300/300V	2.74KG
4X0.3	4.9土0.2	0.5	0.7	69.2	300/300V	3.71KG
4X0.5	6.0土0.2	0.6	0.7	39	300/300V	5.97KG
4X0.75	6.9土0.2	0.6	0.8	26	300/500V	7.61KG
4X1.0	7.6土0.2	0.6	0.8	19.5	300/500V	9.45KG
4X1.5	8.4土0.2	0.7	0.8	13.3	300/500V	13.97KG
4X2.5	10.0土0.2	0.8	1	7.98	300/500V	19.53KG
4X4.0	11.9土0.2	0.8	1.2	4.95	300/500V	27.68KG
4X6.0	14.3土0.2	0.9	1.2	3.65	300/500V	40.72KG

FAQ

1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first begining to the last.Welcome to visit us. We'll pick you up in Hebei.

2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.

3. What’s your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy.You'd better order a suitable quantity to avoid the high freight.Sea transportation is the best option.

4. why should you buy from us not from other suppliers?
Specializing in the production of sheathed power cords, towline cables, high-flexible cables, shielded cable series, network cables, multi-core control cables, flat wires, electronic wires, video cables, elevator video cables, etc.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian



5. Does your company accept OEM production?

Yes, could print your company name, we even custom the quality card to promote your company.
